AX080A002A – Display Module

Part Number : AX080A002A

Function : Display Module

Manufactures : IPS Alpha

Images :

1 page
AX080A002A image

2 page
pinout

Description :

Global LCD Panel Exchange Center www.panelook.com One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com Global LCD Panel Exchange Center www.panelook.com IPS Alpha Technology,Ltd. Date Sep.01,2008 Sheet No. IPS4PS 2601 -AX080A002A-5 Page 1-2/2 One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com Global LCD Panel Exchange Center www.panelook.com RECORD OF REVISION The upper section:Beᰖore revision Date The lower section:After revision Sheet No. Page Summary May.16,2007 IPS4PS 2611-AX080A002A-2 IPS4PS 2611-AX080A002A-3 Added Rev.B 11-2/2 Prevention of ᰓreak noise Aug.20,2007 IPS4PS 2611-AX080A002A-3 IPS4PS 2611-AX080A002A-4 11-2/2 Added Rev.C Changing Mold Frame Diffusion Sheet:D124Z / RBEF Sheet / Diffusion Sheet:D121UY ᜒ Diffusion Sheet:D141Z / Diffusion Sheet:D141Z IPS4PS 2611-AX080A002A-4 IPS4PS 2611-AX080A002A-5 11-2/2 Added Rev.G Changing Mold Frame and lower side mold Sep.01,2008 IPS4PS 2614-AX080A002A-4 14-1/2 A page number is changed by the addition of IPS4PS 2614-AX080A002A-5 14-1/3 new packing specifications. A page number is changed by the addition of new packing specifications. IPS4PS 2614-AX080A002A-5 14-2/3 (Details of new packing specifications) IPS4PS 2614-AX080A002A-4 14-2/2 A page number is changed by the addition of IPS4PS 2614-AX080A002A-5 14-3/3 new packing specifications. IPS Alpha Technology,Ltd. Date Sep.01,2008 Sheet No. IPS4PS 2602 -AX080A002A-5 Page 2-1/1 One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com Global LCD Panel Exchange Center www.panelook.com DESCRIPTION The following specifications are applied to the following TFT-LCD module. Note : Inverter for back light unit is built in this module. Product Name : AX080A002A Place of production : Mobara The factory of production : IPS-Alpha Technology The country of origin : Japan General Specifications Effective Display Area : (H)697.6845×(V)392.256 (mm) Number of Pixels : (H)1,366×(V)768 (pixels) Pixel Pitch : (H)0.51075×(V)0.51075 (mm) Color Pixel Arrangement : R+G+B Vertical Stripe Display Mode : Transmissive Mode Normally Black Mode Top Polarizer Type : Anti-Glare Number of Colors : 16,777,216 (colors) Viewing Angle Range : Super Wide Version (Horizontal & Vertical : 178°, CR្10) Input Signal : 2-channel LVDS (LVDS:Low Voltage Differential Signaling) Back Light : 18 pcs. of EEFL External Dimensions : (H)760.0×(V)450.0×(t)77.0 (mm) Weight : 7,200g typ. IPS Alpha Technology,Ltd. Date Sep.01,2008 Sheet No. IPS4PS 2603 -AX080A002A-5 Page 3-1/1 One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com Global LCD Panel Exchange Center www.panelook.com 1. ABSOLUTE MAXIMUM RATINGS 1.1 Environmental Absolute Maximum Ratings ITEM Temperature Humidity Vibrat […]

3 page

AX080A002A Datasheet
