B30A45VC – Schottky Barrier Diode

Part Number : B30A45VC

Function : Schottky Barrier Diode

Manufactures : KEC semiconductor

Images :

1 page
B30A45VC image

2 page
pinout

Description :

SEMICONDUCTOR B30A45VC SCHOTTKY BARRIER TYPE DIODE (LOW VF TYPE) TECHNICAL DATA SWITCHING TYPE POWER SUPPLY APPLICATION. CONVERTER & CHOPPER APPLICATION. FEATURES Average Output Rectified Current : IO=30A. Repetitive Peak Reverse Voltage : VRRM=45V. Low Peak Forward Voltage : 0.60V(Max.) H L C E A R S F Q D P T G C M K M N MAXIMUM RATING (Ta=25 CHARACTERISTIC Repetitive Peak Reverse Voltage Average Output Rectified Current (Tc=115 ) (Note) Peak One Cycle Surge Forward Current (Non-Repetitive 60Hz) Junction Temperature Storage Temperature Range ) SYMBOL VRRM IO IFSM Tj Tstg RATING 45 30 UNIT V A J 1. ANODE 2. CATHODE 3. ANODE 350 -40 150 -55 150 A TO-220AB Note : average forward current of centertap full wave connection. 2 1 3 ELECTRICAL CHARACTERISTICS (Ta=25 CHARACTERISTIC Peak Forward Voltage Repetitive Peak Reverse Current Thermal Resistance Note : A value of one cell (Note) (Note) (Note) ) TEST CONDITION IFM=15A VRRM=Rated Juction to Case MIN. TYP. MAX. 0.60 150 1.7 /W UNIT V SYMBOL VFM IRRM Rth(j-c) 2008. 12. 18 Revision No : 0 O 1 2 3 DIM A B C D E F G H J K L M N O P Q R S T MILLIMETERS 10.30 MAX 15.30 MAX 0.80 _ 0.20 Φ3.60 + 3.00 6.70 MAX _ 0.50 13.60 + 5.60 MAX 1.37 MAX 0.50 1.50 MAX 2.54 4.70 MAX 2.60 1.50 MAX 1.50 _ 0.20 9.50 + _ 0.20 8.00 + 2.90 MAX B 1/2 B30A45VC IF – V F REVERSE CURRENT IR (mA) 100 IR – V R 100 10 1.0 0.1 0.01 0.001 Tj =25 C Tj =150 C Tj =125 C FORWARD CURRENT IF (A) Tj=150 C 10 Tj=25 C 1 0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0 10 20 30 40 50 FORWARD VOLTAGE VF (V) REVERSE VOLTAGE VR (V) IF – TC AVERAGE FORWARD CURRENT IF(AV) (A) AVERAGE FORWARD CURRENT IF(AV) (A) 40 20 IF – TA RATED VOLTAGE APPLIED R ΘJA=16 C/W R ΘJA=62.5 C/W DC (NO HEAT SINK) 30 15 20 DC 10 DC 10 0 60 RATED VOLTAGE APPLIED R ΘJC =1.7 C/W 5 80 100 120 140 160 0 0 40 80 120 160 CASE TEMPERATURE Tc ( C) AMBIENT TEMPERATURE TA ( C) AVERAGE FORWARD POWER DISSIPATION PF(AV) (W) PF(AV) – IF(AV) 40 CAPACITANCE C J (pF) 1000 C – VR 30 20 DC 10 0 0 10 20 30 40 100 0 5 10 15 20 25 30 35 40 AVERAGE FORWARD CURRENT IF(AV) (A) REVERSE VOLTAGE VR (V) 2008. 12. 18 Revision No : 0 2/2 […]

3 page
