BT2025BL PDF Datasheet – Classic V2 Stadium Scoreboard

Part Number : BT2025BL

Function : Classic V2 Stadium scoreboards

Manufactures : Bodet

Images :

1 page
BT2025BL image

Description :

The BT2025BL scoreboard range is aimed at time keeping and scoring of sport
events in stadiums.

DISPLAY

• Timer display in minutes and seconds or time display.
• Scores from 0 to 99.
• Digit size : 25 cm.
• Readability : 120 m.

STANDARD KEYBOARD ALPHA SCORE

• For use under shelter or in the press room.
• Wireless communication.
• Time display of the time beside the game.
• Power supply : 230V with battery power reserve.

PORTABLE KEYBOARD POCKET

• For outdoor use.
• Very easy to use.
• Horn for rugby (option).
• Time display of the time beside the game.
• Wireless communication.
• Power supply : 9V batter

[…]

2 page
pinout

TECHNICAL DESCRIPTION :

• High brightness SMD LED display.

• Viewing angle of 160°.

• Perfect visibility under all lighting conditions.

• Luminosity adjustment from the keyboard.

• Offi cial time display with radio synchronisation (FI or DCF) in option.

• Optional advertising panels on all models
