HC80UW – RESISTANCE WELD MINIATURE CRYSTAL

Part Number : HC80UW

Function : RESISTANCE WELD MINIATURE CRYSTAL

Manufactures : Fox Electronics

Images :

1 page
HC80UW image

2 page
pinout

Description :

RESISTANCE WELD MINIATURE CRYSTAL (GULLWING) Pb Free HC80UW Pb Free CRYSTALS The HC80UW Quartz Crystal is a miniature resistance welded package that provides for an excellent hermetic seal and frequency aging. This high quality crystal offers a smaller footprint in a wide frequency range. FEATURES • Miniature Package • Wide Frequency Range • Small Footprint • Low Profile • Excellent Aging • HC80UW STANDARD SPECIFICATIONS – PARAMETERS Frequency Range Frequency Tolerance Frequency Stability, ref @ 25ºC Temperature Range Operating (TOPR) Storage (TSTG) Shunt Capacitance (Co) Load Capacitance (CL) Drive Level Aging CONDITIONS Ta = 25ºC Ta = -20ºC ~ +70ºC MIN 3.579545 -30 -50 -20 -40 Customer Specified 3.579545 ~ 200.000 MHz Ta = 25ºC; per year 10.0 -3.0 MAX 200.000 +30 +50 +70 +85 7.0 Series 1.0 +3.0 UNITS MHz PPM PPM ºC pF pF mW PPM Frequency Range (MHz) Operating Mode Max ESR W Frequency Range (MHz) Operating Mode Max ESR W Fundamental Fundamental 300 10.000+ ~ 11.000 60 3.579545~ 4.000 Fundamental Fundamental 250 11.000+ ~ 27.000 40 4.000+ ~ 5.000 3rd OT Fundamental 180 25.000 ~ 65.000 60 5.000+ ~ 6.000 5th OT Fundamental 120 60.000 ~ 130.000 100 6.000+ ~ 7.000 7th OT Fundamental 100 130.000 ~ 200.000 150 7.000+ ~ 8.000 Fundamental 90 8.000+ ~ 10.000 – Other tolerances, stabilities & operating temperature ranges available. Consult Fox Customer Service for specific requirements, or use crystal order form on page 6. All specifications subject to change without notice. Rev. 05/03/00 All dimensions are in millimeters. FOX Electronics 5570 Enterprise Parkway Fort Myers, Florida 33905 941-693-0099 FAX 941-693-1554 http://www.foxonline.com © 2000 FOX ELECTRONICS 13 […]

3 page

HC80UW Datasheet
