HCA0207 – Carbon Film Resistors

Part Number : HCA0207

Function : Carbon Film Resistors

Manufactures : Vishay

Images :

1 page
HCA0207 image

2 page
pinout

Description :

HCA0207 Vishay Draloric Carbon Film Resistors, Power Type FEATURES • Carbon film resistor with high power rating. • Stable film structure on special ceramic • Good overload and pulse withstanding characteristics • For applications in power electronics and general purpose commercial electronics STANDARD ELECTRICAL SPECIFICATIONS MODEL POWER RATING P 70˚C W 0.8 LIMITING ELEMENT VOLTAGE MAX. VƆ 500 TEMPERATURE COEFFICIENT ppm / K – 220 to – 1500 TOLERANCE % 1 2 RESISTANCE RANGE E-SERIES Ω 10R-1M0 4R7-2M2 48 48 24 HCA0207 • Coating: green 5 4R7-2M2 • Marking see appropriate catalog or web page • Additional yellow dot at the beginning of the code TECHNICAL SPECIFICATIONS PARAMETER Rated Dissipation at 70°C Limiting Element Voltage1) Max. Pulse Voltage Insulation Voltage (1 min) Thermal Resistance Insulation Resistance Category Temperature Range Failure Rate Terminal Strength, axial Weight 1) UNIT W VƆ VƆ V eff K/W Ω °C 10-9/h N g HCA0207 0.8 ≤ 500 1050 ≥ 700 130 ≥ 1010 – 55 / ± 175 < 20 > 50 0.22 Rated Voltage PxR PACKAGING MODEL REEL BOX PIECES / REEL HCA0207 5000 CODE R5 MIN. ORDER QUANTITY PACKAGING UNITS 1 PIECES / BOX 5000 2000 CODE A5 A2 MIN. ORDER QUANTITY PACKAGING UNITS 1 2 ORDERING INFORMATION HCA0207 MODEL TC ppm / K 100R RESISTANCE VALUE Ω 2% TOLERANCE ±% A5 PACKAGING A5-Ammopack 5000pcs www.vishay.com 104 For Technical Questions, contact ff1aresistors@vishay.com Document Number 20136 Revision 02-Aug-02 Free Datasheet http:/// HCA0207 Carbon Film Resistors, Power Type DIMENSIONS 6 mm L1 L D d Vishay Draloric DIMENSIONS [in millimeters] MODEL HCA0207 D max. 2.5 -0.3 L 6.3 -0.5 L1 max 7.5 B 53 ±1 d 0.6 e 7.5 e B · Taping in acc. with IEC60286-1 · D and L measured in acc. with IEC60294 · d according to IEC60301 RATED POWER IN % 120 100 80 60 40 20 300 TEMPERATURE RISE IN ˚C 200 100 0 0 0.5 1.0 1.5 TEMPERATURE RISE 2.0 2.5 POWER IN WATTS 0 – 55 – 25 0 25 50 75 70 100 DERATING 125 150 175 200 AMBIENT TEMP.IN ˚C PERFORMANCE TEST Endurance 1000 hours at 70°C IEC 60115-1 4.25.1 Endurance at UCT IEC60115-1 4.25.3 Overload Test IEC 60115-1 4.13 Thermal Shock IEC 60115-1 4.19, IEC 60068-2-14 Climatic Sequence IEC 60115+1 4.23 Damp Heat Steady State IEC 60115-1 4.24, IEC 60068-2-3 Resistance to Soldering Heat IEC 60115-1 4.18, IEC 60068-2-20 Robustness of Terminations IEC 60115-1 4.16, IEC 60068-2-21 Vibration IEC 60115-1 4.22 1) For a resistance range of 10R to 1M0 CONDITIONS OF TEST 1000 hours at 70°C, 1.5 hours “ON”, 0.5 hours “OFF” 1000 hours at 155°C without load Short time overload 5 seconds at 2.5 x rated voltage or ≤ twice the limiting element voltage Rapid change between upper and lower category temperature Dry heat, damp heat cyclic, cold, low air pressure 56 days at 40°C and 93% relative humidity 10 seconds at 260°C solder bath temperature Tensile, bending and torsion 0.75mm or 10g, 10Hz-500Hz 6 hours REQUIREMENTS ≤ ± 2. […]
