HK3FF-DC5V – SUBMINIATURE HIGH POWER RELAY

Part Number : HK3FF-DC5V

Function : SUBMINIATURE HIGH POWER RELAY

Manufactures : HUI KE

Images :

1 page
HK3FF-DC5V image

2 page
pinout

Description :

Free Datasheet http:// HK 3FF SUBMINIATURE HIGH POWER RELAY Features ● 15A switching capability ● 1 Form A &C configurations ● Subminiature, standard PCB layout ● Plastic sealed and flux proofed types available ● Environmental friendly product (RoHS compliant) ● Outline Dimensions: (19.0 x 15.5 x 15.8) mm ■ CONTACT DATA Contact Form Contact Material Contact Ratings Max Switching Voltage Max Switching Current Max Switching Power Contact Resistance Electrical Life Mechanical Life 1A, 1C Silver Alloy 10A 277VAC 30VDC 16VDC 15A 2770VA 210W 100MΩ(at 1A 6VDC) 1X105Ops(30Ops/min) 1X107Ops(300Ops/min) ■ GENERAL DATA Insulation Resistance Dielectric Strength Operate Time Release Time Temperature Range Shcok Resistance Vibration Resistance Humidity Weight Safety Standard Between coil & contacts Between open contacts Functional Destructive 100MΩ 500VDC 1500VAC 1min 750VAC 1min Max. 10ms Max. 5ms – 40℃ to +70℃ 98m/s2 (10g) 980m/s2 (100g) 10 to 55Hz 1 […]

3 page

HK3FF-DC5V Datasheet
