JC186VA13U PDF – 18.1 Inch, TFT Monitor, Service Manual

Part Number : JC186VA13U

Function : Service Manual

Manufactures : ETC

Images :

1 page
JC186VA13U image

Description :

JC186VA13U  monitor is manufactured and tested on a ground principle that a user’s safety comes first. However, improper use or installation may cause damage to the monitor as well as to the user.
Carefully go over the following WARNINGS before installing and keep this guide handy.

Service Manual TABLE OF CONTENTS PAGE 1. PRECAUTION AND NOTICES – 1~2 1.1. SAFETY PRECAUTIONS 1 1.2. PRODUCT SAFETY NOTICE – 1 1.3. SERVICE NOTES 1 2. 3. SERVICE TOOL & EQUIPMENT REQUIRED 2 SPECIFICATIONS – 2~4 3.1. PRODUCT SPECIFICATIONS 2 3.2. FACTORY PRESET MODE TIMING CHART 3 3.3. D-SUB CONNECTOR 4 EXPLODED VIEW AND PARTS LIST – 5~6 4.1. EXPLODED VIEW 5 4.2. EXPLODED VIEW PARTS LIST 6 BLOCK DIAGRAM 7 SCHEMATIC DIAGRAM 8~21 6.1. ADC – 8 6.2. TP6732 – 9 6.3. MPU 10 6.4. SAA7118 – 11 6.5. VX1520 – 12 6.6. SDRAM – 13 6.7. AUDIO 14 6.8. PANEL INTERFACE – 15 6.9. POWER 16 6.10. TUNER – 17 6.11. KEYPAD & IR – 18 6.12. […]

PRODUCT SPECIFICATIONS :

1. LCD Panel 18.1″ TFT

2. Power Management

(1) Energy Star compliant VESA

(2) DPMS compatible < 5W

3. Displayable Resolution XGA 1024×768 max.

4. Pixel Dimension 0.3585×0.3585mm

5. LCD Display Color 16.7M Color Max. (8bit)

JC186VA13U Datasheet
