K0339 – Indexing plungers

Part Number : K0339

Function : Indexing plungers

Manufactures : Kipp

Images :

1 page
K0339 image

2 page
pinout

Description :

K0339 Indexing plungers Item description/product images Description Material: Steel version: Indexing pin hardened: grade 5.8. Stainless steel version, Indexing pin hardened Threaded sleeve 1.4305 Indexing pin 1.4034 Indexing pin not hardened Threaded sleeve 1.4305 Indexing pin 1.4305 Mushroom knob black grey thermoplastic Version: Steel version: Indexing pin hardened, ground, black oxidised. Stainless steel version: Indexing pin hardened, ground and bright. Indexing pin not hardened, ground and bright. Note: Indexing plungers are used to prevent any change in locking position due to lateral forces. A new locking position can only be set after the pin has been manually disengaged. Form C or D is recommended for applications in which the pin is disengaged over extended periods and should be prevented from springing back. On request: Special versions. © HEINRICH KIPP WERK KG www.kipp.com · info@kipp.com 1/2 K0339 Indexing plungers Drawings Overview of items Indexing plungers, ste […]

3 page

K0339 Datasheet
