K10A600 – TK10A60D

Part Number : K10A600

Function : TK10A60D

Manufactures : Toshiba

Images :

1 page
K10A60D image

2 page
pinout

Description :

TK10A60D TOSHIBA Field Effect Transistor Silicon N Channel MOS Type (π-MOSⅦ) TK10A60D Switching Regulator Applications Unit: mm • Low drain-source ON-resistance: RDS (ON) = 0.62 Ω (typ.) High forward transfer admittance: |Yfs| = 6.0 S (typ.) Low leakage current: IDSS = 10 μA (VDS = 600 V) Enhancement mode: Vth = 2.0 to 4.0 V (VDS = 10 V, ID = 1 mA) Absolute Maximum Ratings (Ta = 25°C) Characteristics Drain-source voltage Drain-gate voltage (RGS = 20 kΩ) Gate-source voltage DC Drain current (Note 1) Symbol VDSS VDGR VGSS ID IDP PD EAS IAR EAR Tch Tstg Rating 600 600 ±30 10 40 45 363 10 4.5 150 -55 to 150 A Unit V V V 1: Gate 2: Drain 3: Source Pulse (t = 1 ms) (Note 1) JEDEC W mJ A mJ °C °C ― SC-67 2-10U1B Drain power dissipation (Tc = 25°C) Single pulse avalanche energy (Note 2) Avalanche current Repetitive avalanche energy (Note 3) Channel temperature Storage temperature range JEITA TOSHIBA Weight : 1.7 g (typ.) Note: Using continuously under heavy loads (e.g. the application of high temperature/current/voltage and the significant change in temperature, etc.) may cause this product to decrease in the reliability significantly even if the operating conditions (i.e. operating temperature/current/voltage, etc.) are within the absolute maximum ratings. Please design the appropriate reliability upon reviewing the Toshiba Semiconductor Reliability Handbook (“Handling Precautions”/’’Derating Concept and Methods’’) and individual reliability data (i.e. reliability test report and estimated failure rate, etc). Thermal Characteristics Characteristics Thermal resistance, channel to case Thermal resistance, channel to ambient Symbol Rth (ch-c) Rth (ch-a) Max 2.78 62.5 Unit °C/W °C/W 1 2 Note 1: Ensure that the channel temperature does not exceed 150℃. Note 2: VDD = 90 V, Tch = 25°C (initial), L = 6.36 mH, RG = 25 Ω, IAR = 10 A Note 3: Repetitive rating: pulse width limited by maximum channel temperature This transistor is an electrostatic-sensitive device. Handle with care. 3 1 2009-09-29 TK10A60D Electrical Characteristics (Ta = 25°C) Characteristics Gate leakage current Drain cut-off current Drain-source breakdown voltage Gate threshold voltage Drain-source ON-resistance Forward transfer admittance Input capacitance Reverse transfer capacitance Output capacitance Rise time Turn-on time Switching time Fall time Turn-off time Total gate charge Gate-source charge Gate-drain charge tf toff Qg Qgs Qgd VDD ∼ − 400 V, VGS = 10 V, ID = 10 A Duty ≤ 1%, tw = 10 μs Symbol IGSS IDSS V (BR) DSS Vth RDS (ON) ⎪Yfs⎪ Ciss Crss Coss tr ton 10 V VGS 0V 50 Ω ID = 5 A VOUT VDS = 25 V, VGS = 0 V, f = 1 MHz Test Condition VGS = ±30 V, VDS = 0 V VDS = 600 V, VGS = 0 V ID = 10 mA, VGS = 0 V VDS = 10 V, ID = 1 mA VGS = 10 V, ID = 5 A VDS = 10 V, ID = 5 A Min ⎯ ⎯ 600 2.0 ⎯ 1.5 ⎯ ⎯ Typ. ⎯ ⎯ ⎯ ⎯ 0.62 6.0 1350 6 135 22 55 15 100 25 16 9 Max ±1 10 […]

3 page

K10A60D Datasheet
