LTM185AT01 – Display Module

Part Number : LTM185AT01

Function : Display Module

Manufactures : Samsung

Images :

1 page
LTM185AT01 image

2 page
pinout

Description :

www.DataSheet.co.kr PRODUCT INFORMATION ISSUED DATE : 2008-09-02 SAMSUNG -LCD PRODUCT SAMSUNG TFT TFT-LCD PRODUCT INFORMATION INFORMATION MODEL MODEL : : LTM185AT01 LTM185AT01 Note : This is Product Information is subject to change after 3 months of issuing date. Application Engineering Part 1, HD LCD Division Samsung Electronics Co . , LTD. MODEL LTM185AT01 Page 1/31 Datasheet pdf – http://www.DataSheet4U.net/ www.DataSheet.co.kr PRODUCT INFORMATION Contents General Description – (3) 1. Absolute Maximum Ratings – (4) 2. Optical Characteristics – (6) 3. Electrical Characteristics (11) 3.1 TFT LCD Module 3.2 Back Light Unit 4. Block Diagram – (16) 4.1 TFT LCD Module 4.2 Back Light Unit 5. Input Terminal Pin Assignment (17) 5.1 Input Signal & Power 5.2 LVDS Interface 5.3 Back Light Unit 5.4 Input Signals, Basic Display Colors and Gray Scale of Each Color 6. Interface Timing – (23) 6.1 Timing Parameters (DE only mode) 6.2 Timing Diagrams of interface Signal (DE only mode) 6.3 Power ON/OFF Sequence 6.4 LVDS Input Characteristics 6.5 VDD Power Dip Condition 7. Outline Dimension – (27) 8. General Precaution (29) 8.1 Handling 8.2 Storage 8.3 Operation 8.4 Others MODEL LTM185AT01 Page 2/31 Datasheet pdf – http://www.DataSheet4U.net/ www.DataSheet.co.kr General Description Description PRODUCT INFORMATION LTM185AT01 product is a color active matrix liquid crystal display (LCD) that uses amorphous silicon TFT (Thin Film Transistor) as switching components. This model is composed of a TFT LCD panel, a driver circuit and a back light unit. The resolution of a 18.5” is 1366 X 768 and this model can display up to 16.7 millions colors. Features High contrast ratio, high aperture structure TN (Twisted Nematic) mode Wide Viewing Angle High speed response HD (1366 x 768 pixels) resolution Low power consumption 2 CCFLs (Cold Cathode Fluorescent Lamp) DE (Data Enable) only mode LVDS (Low Voltage Differential Signaling) interface (1pixel/clock) Compact Size Design RoHS compliance TCO’03 compliance Applications Workstation & desktop monitors Display terminals for AV application products Monitors for industrial machine – If the module is used to other applications besides the above, please contact SEC in advance. General Information Items Pixel Pitch Active Display Area Surface Treatme […]

3 page

LTM185AT01 Datasheet
