ZC-1021H-2-7 PDF – 2.4Ghz Outdoor CPE Wireless

Part Number : ZC-1021H-2-7

Function : Outdoor Wireless

Manufactures : Zcomax Technologies

Images :

1 page
ZC-1021H-2-7 image

2 page
pinout

Description :

ZC-1021H-2-7 Data Sheet Skyport Series Skyport ZC-1021H-2-7 2.4Ghz Outdoor CPE Skyport Series Outdoor Wireless Today’s wireless market, more specifically the outdoor wireless market, continues to demand higher transmit power, greater dependability and advanced feature sets. To that end, Zcomax has released it’s latest line of customer premise equipment to utilize the 2.4GHz unlicensed spectrum, the ZC-1021H-2-7. The ZC-1021H-2-7 is an all-in-one weatherproof unit with high output power and all the essential features for point to point and access point to client connections. The 7dBi antenna compliments the proven Atheros AR2315 based radio or you may choose to use an antenna of your choosing with the external SMA connector, allowing for greater flexibility in implementation. Web based configuration and remote access add ease of deployment while the WPA / WPA2 and Access Control functions add an additional layer of security to your network infrastructure. Please contact a sales representative for more information on samples, promotional pricing and availability on the Skyport series or any other Zcomax wireless products Key Features • • • • • • • • IEEE 802.11b/g compliant Up to 21.5dBm output power WPA / WPA2 wireless security External antenna connector 802.11i RoHS compliant Adjustable output power Chipset: Atheros AR5006 Family o SOC: Atheros AR2315 ZC-1021H-2-7 at a Glance Chipset Transmit Power Receive Sensitivity Antenna Atheros AR2315 21.5 dBm -94 dBm @ 6 Mbps data rate 7 dBi Omni-directional SMA-RP Antenna Connector IEEE Radio RoHS Interface • SMA-RP antenna connector Data Sheet September 2009 Zcomax Technologies, Inc California New Jersey United Kingdom China © Copyright 2000 – 2009 Zcomax Technologies, Inc. All rights reserved, specifications may be subject to change without prior notice. AirRunner and Zcomax are registered trademarks of Zcomax Technologies, Inc. Other trademarks are the properties of their respective holders. ZX-ZC-1021H-2-7-DS ZC-1021H-2-7 Data Sheet Skyport Series Radio Specification Chipset Antenna Memory Modulation RF Frequency Atheros AR2315 7dBi Omni-directional antenna – SMA-RP external antenna connector Flash 4MB 16MB SDRAM OFDM: BPSK, QPSK, 16-QAM, 64-QAM / DSSS: DBPSK, DQPSK, CCK USA (FCC) 2.412GHz – 2.462GHz (Chan. 1-11) 802.11b Europe (ETSI) 2.412GHz – 2.472GHz (Chan. 1-13) 802.11g Channel 11 Channel 1 Channel 6 Channel 11 RF Output Power (± 1.5dB) Channel 1 Channel 6 17.5dBm 21.5dBm 19dBm 15dBm 21.5dBm 17.5dBm 802.11g @ PER: 10% 54Mbps: ≤ -74dBm 48Mbps: ≤ -76dBm Receiver Sensitivity- 36Mbps: ≤ -81dBm 24Mbps: ≤ -83dBm 18Mbps: ≤ -87dBm 12Mbps: ≤ -87dBm 9Mbps: ≤ -86dBm 6Mbps: ≤ -94dBm 802.11b @ PER: 8% 11Mbps: ≤ -88dBm 5.5Mbps: ≤ -90dBm 2Mbps: ≤ -92dBm 1Mbps: ≤ -97dBm Firmware Specification Function Detail Of The Function IEEE 802.11b/g Standards Compliance 10Base-T and 100Base-TX physical layer IEEE 802.3 and 802.3u Web La […]
