A1626 Datasheet PDF – 400V, 2.0A, PNP Transistor – NEC

Part Number : A1626

Function : – 2.0A, – 400V, PNP Silicon Transistor

Package : TO-126 Type

Manufacturers : NEC ( Renesas Technology )

Pinouts :

A1626 datasheet

Description :

The 2SA1626 is designed for general purpose amplifier and high speed switching applications.

Features

1. High Voltage.
2. High Speed Switching.
3. Low Collector Saturation Voltage.

Absolute maximum ratings ( Ta = 25°C )

1. Collector to Base Voltage : Vcbo = – 400V
2. Collector to Emitter Voltage : Vceo = – 400V
3. Emitter to Base Voltage : Vebo = – 7.0V
4. Collector Current (DC ) : Ic = – 2.0A
5. Collector Current (pulse) : Ic = – 4.0A
6. Storage Temperature : – 55 to +150°C
7. Junction Temperature : 150°C

Other data sheets within the file : 2SA1626
