ACM1602L Datasheet PDF

Part Number : ACM1602L

Function : 0.0-6.5V; 5x7dots with cursor; 16characters x 2lines; dot size0.56×0.61mm; AZ display

Manufacturers : AZ Displays

Pinouts :

ACM1602L datasheet

Description :

ACM1602L SERIES LCD MODULE

* Number of Characters : 16 characters x 2 line
* Character Format : 5 x 7 dots with cursor
* Overall Module Size (W x H x D) :
80.0x 36.0x max 14.5for LED backlight version
80.0x 36.0x max 9.5for reflective or EL backlight version
* Dot Size (W x H) : 0.55x 0.50
* Dot Pitch (W x H) : 0.60x 0.55
* Duty : 1/16
* Controller IC : KS0066
* LC Fluid Options : STN
* Polarizer Options : Reflective, Transflective, Transmissive
* Backlight Options : EL, LED
* Temperature Range Options : Standard, Wide temp

Datasheet PDF Download

ACM1602L pdf

Other data sheets within the file :
ACM1602L,ACM1602L-FEBD-T,ACM1602L-FEBS-T,ACM1602L-FEFD-T,ACM1602L-FEFS-T
