DL5250B Datasheet PDF – 20V, 500mW, Silicon Zener Diode

Part Number : DL5250B, DL5221B Thru DL5259B

Function :  20V, GLASS SILICON ZENER DIODE

Package : DL-35 Type

Manufacturers : DC COMPONENTS

Pinouts :

DL5250B datasheet



Description :

DL5221B Thru DL5259B

– Voltage Range:2.4V to 39V
– Double slug type construction

Mechanical Data

1. Case : Glass case Minimelf DL-35
2. Terminals:Solder plated, solderable per MIL-STD-750, Method 2026
3. Polarity: Color band denotes cathode end
4. Mounting position: Any
5. Weight: 0.05 gram Approx

Other data sheets within the file : DL5221B, DL5222B, DL5223B, DL5224B, DL5225B

DL5250B Datasheet PDF Download

DL5250B pdf
