EG-530YD-9B PDF – 9V DC Motor, 4000 RPM

Part Number : EG-530YD-9B

Function : 9V DC Motor, 4000 RPM

Manufactures : ETC

Images :

EG-530YD-9B image

Description :

Data Group: 169 Code: 1112011 Weight: Decsription: EG-530YD-2B Applications: RATED MFG MODEL VOLTAGE VDC WORKING VOLTAGE VDC RATED LOAD RATED SPEED rpm 2000 RATED LOAD CURRENT mA(TYP) 128 140 99 108 LOAD FLUCTUATION (YTP) STARTING TOROUE(MIN) g·cm mN·m g·cm mN·m rpm/ g·cm 1.5 50 EG-530YD-9B 9 6.3-11.7 10 0.98 4000 2000 4 1.5 4.9 EG-530YD-2B 12 8.4-15.6 10 0.98 4000 4 55 5.39 […]

Spec

1. Rotation : CCW, Anticlockwise looking from Pulley end.
2. RPM : 2000 to 4000
3. Voltage : 9 Volts DC.
4. Motor Body Diameter approx : 33.5mm
5. Motor Body Length approx : 25mm
6. Spindle Diameter : 2mm
7. Top Pulley Outer Diameter approx : 9.55mm
8. Top V Belt Pulley Inner Diameter approx : 7.3mm
9. Bottom Pulley Outer Diameter Approx : 12mm
10. Bottom Puller Inner Diameter Approx : 9.7mm
11. Weight: 75g.

Applications : Casette, CD Player, CD-ROM, VCD, DVD, DV-ROM

EG-530YD-9B Datasheet
