K2933 Datasheet PDF – MOSFET, 60V, 15A, N-Ch, Transistor

Part Number: K2933

Function: 60V, 15A, N-Channel MOSFET, Transistor

Package: TO–220CFM Type

Manufacturer: Renesas Electronics

Image and Pinouts:

K2933 datasheet



Description:

The K2933 is 60V, Silicon N-Channel MOSFET.

An N-channel MOSFET (Metal Oxide Semiconductor Field Effect Transistor) is a type of field effect transistor (FET) that uses an N-type semiconductor material as the conducting channel to control the flow of current.

N-channel MOSFETs are widely used in a variety of electronic applications due to their high input impedance, fast switching speeds, and low power consumption. They are commonly used as switches, amplifiers, and voltage regulators.

Features:

1. Low on-resistance : RDS(on)= 0.040Ω typ.

2. 4V gate drive devices.

3. High speed switching



Absolute Maximum Ratings (Ta = 25°C)

1. Drain to source voltage: VDSS = 60 V

2. Gate to source voltage: VGSS = ± 20 V

3. Drain current: ID = 15 A

4. Channel dissipation: Pch = 25 W

5. Channel temperature: Tch = 150 °C

6. Storage temperature: Tstg = -55 to +150 °C



Applications:

1. High Speed Power Switching

Other data sheets are available within the file: 2SK2933
