NKE1205S Datasheet PDF – 1W, DC-DC Converter

Part Number: NKE1205S

Function: 1W single output DC-DC converter

Package: SIP 4 Pin Type

Manufacturer: C&D TECHNOLOGIES


NKE1205S datasheet



The NKE sub-miniature series of DC-DC Converters is particularly suited to isolating and/or converting DC power rails.

A smaller package size, improved efficiency, lower output ripple and 3kVDC isolation capability through state of the art packaging and improved technology. The galvanic isolation allows the device to be configured to provide an isolated negative rail in systems where only positive rails exist.

Ordering Information :



1. 3kVDC Isolation

2. Efficiency to 81 %

3. Single Isolated Output

4. NO Heatsink required.

5. Fully Encapasulated with toroidal magnetics


NKE1205S Datasheet PDF Download

NKE1205S pdf

Other data sheets are available within the file:

NKE0505S, NKE0509D, NKE0509S, NKE0512S, NKE0515S
