OKI OM5653C Datasheet – 40 Gb/s EA Modulator ( PDF )

Part Number: OM5653C

Function: 40 Gb/s EA Modulator with Polarization Maintaining Fiber, Built-in Cooler

Package: Module type

Manufacturer: OKI

OKI OM5653C Modulator

Description

OM5653C, OM5653C-30B is a C-band electro-absorption (EA) modulator for 40 Gb/s operation with low chirp characteristics in a hermetic sealed package with a V connector.

Features

1. Low chirp : α < 0.5
2. 40Gb/s NRZ operation
3. Low operating voltage : 3 Vpp
4. High modulation bandwidth over 30 GHz
5. Built-in thermoelectric cooler (TEC)

Pinout
OM5653C datasheet pdf
1. THERMISTOR
2. TEC CATHODE
3. THERMISTOR
4. NC
5. TEC ANODE

Applications

1. SONET/SDH applications (OC-768)
2. VSR/Metro/Long-haul DWDM system applications

Other data sheets are available within the file: OM5653C-30B
