IN1M101 Datasheet – Precision AC Brown-out Supervisor IC

Part Number : IN1M101, IN1M101-T6G

Function : Precision AC Brown-out Supervisor IC

Package : SOT-26

Manufacturers : Infinno

Image : IN1M101 image

Description :

IN1M101 provides a precise comparator to detect the rectified AC voltage, which could protect the SPS when AC voltage is low. At the same time, the ic also provides the delay time to noise immunity.


1. The Brown-out protection (BOP) setting by two resistor and auto restart.
2. Wild operation voltage range.
3. Two faults output
4. Low standby current consumption
5. High noise immunity
6. RoHS compliant and Halogen free


1. FPO : Fault protect pin
2. VSS : Ground
3. VCC : Power supply
4. NDFPO : Non-Delay Fault protect pin
5. CD : Delay time setting capacitor
6. IN1 : Comparator passive terminal input1

IN1M101 Datasheet


1. TV open frame SMPS
2. Adapter DVD and CD(R)

IN1M101 Datasheet
