C3089 Datasheet PDF – Vceo=500V, NPN Transistor – Sanyo

Part Number : C3089

Function : 7A, 500V, NPN Triple Diffused Planar Silicon Transistor

Package : TO-3PB Type

Manufacturers : SANYO ( Panasonic )

Images :

C3089 datasheet

Description :

1. High breakdown voltage (VCBO≥800V).
2. Fast switching speed.
3. Wide ASO.

Absolute Maximum Ratings

1. Collector-to-Base Voltage : VCBO = 800 V
2. Collector-to-Emitter Voltage : VCEO = 500 V
3. Emitter-to-Base Voltage : VEBO = 7 V
4. Collector Current : IC = 7 A
5. Collector Current (Pulse) : ICP = 14 A
6. Base Current : IB = 3 A
7. Collector Dissipation : Pc = 2.5 W
8. Junction Temperature : Tj = 150°C
9. Storage Temperatue : Tsg = -55 ~ +150°C

Pinout :

Applications

1. Switching Regulator

Test Circuit

Other data sheets within the file : 2SC3089

C3089 Datasheet PDF Download

C3089 pdf
