D5703 Datasheet – 800V, NPN Transistor, KSD5703

Part Number : D5703, KSD5703

Function : 800V, NPN Transistor

Package : TO-3PF Type

Manufacturers : Fairchild Semiconductor

Image :

D5703 datasheet

Description :

This is 800V, 10A, NPN Triple Diffused Planar Silicon Transistor.

Features :

1. High Collector-Base Voltage : VCBO=1500V

2. High Switching Speed tF= 0.3µs (Max.)

3. For Color TV

Image and Pinout :

Absolute Maximum Ratings

1. Collector-Base Voltage : VCBO = 1500 V

2. Collector-Emitter Voltage : VCEO = 800 V

3. Emitter-Base Voltage : VEBO = 6 V

4. Collector Current (DC) : IC = 10 A

5. Collector Current (Pulse) : ICP = 30 A

6. Collector Dissipation (TC=25°C) : PC = 70 W





KSD5703 = Vcbo1500 V.- Vceo 800 V.- Ic 10 A. -70 W.
BU2520A = CTV-HA, hi-res, 1500/800V, 10A, 125W
BU2522A = CRT-HA, hi-res, 1500/800V, 10A, 125W
BU2525A = CTV-HA, hi-res, 1500/800V, 12A, 125W
BUH1015 = CRT-HA, hi-res, 1500/700V, 14A, 160W
BU2527A = CRT-HA, hi-res, 1500/800V, 12A, 125W
2SD2646 = CTV-HA, 1500/800V, 10A, 80W
2SD2581 = CTV-HA, 1500/800V, 10A, 70W

Applications :

1. High Voltage Color Display Horizontal Deflection Output (No Damper Diode)



D5703 Datasheet PDF Download



Other data sheets within the file : KSD5703, 2SD5703

D5703 pdf

C8050 Transistor – 2W Output Amplifier – USHA

Part Number : C8050

Function : 2W Output Amplifier Of portable Radios In Class B Push-Pull Operation

Manufacturers : USHA ( INDIA ) LTD

Image and Pinout

c8050-transistor-pinout



Absolute Maximum Ratings ( Ta = 25’C )

1. Collector-Base Voltage : Vcbo = 40V
2. Collector-Emitter Voltage : Vceo = 25V
3. Emitter-Base Voltage : Vebo = 6V
4. Collector Current : Ic = 1.5A
5. Collector Dissipation : Pc = 1W
6. Junction Temperature : Tj = 150’C



Detail Information

c8050-datasheet

Features

1. Complimentary to SS8550
2. Collector Current Ic = 1.5A
3. Collector Dissipation Pc = 2W ( Tc = 25’C)



C8050 Transistor Datasheet

C8050 pdf
