TPS43060RTE Datasheet PDF – Boost DC-DC Controller

Part Number : TPS43060RTE

Marking : 43060

Function : TPS4306x Low Quiescent Current Synchronous Boost DC-DC Controller

Package : WQFN 16 Pin Type

Manufacturers : Texas Instruments

Pinouts :

TPS43060RTE datasheet


Description :

The TPS43060, TPS43060RTE and TPS43061 are low IQ current mode synchronous boost controllers with wide-input voltage range from 4.5 to 38 V (40 V absolute max) and boosted output range up to 58 V.

Synchronous rectification enables high-efficiency for high-current applications, and lossless inductor DCR sensing further improves efficiency. The resulting low-power losses combined with a 3-mm × 3-mm WQFN-16 package with PowerPAD™ supports high power-density and high-reliability boost converter solutions over extended (–40°C to 150°C) temperature range.

Features :

1. Current-Mode Control With Internal Slope Compensation

2. Adjustable Frequency from 50 kHz to 1 MHz

3. Synchronization Capability to External Clock

4. Adjustable Soft-Start Time

5. Inductor DCR or Resistor Current Sensing


TPS43060RTE Datasheet PDF Download

TPS43060RTE pdf

Other data sheets within the file :

43060, 43061, TPS43060, TPS43060-RTE, TPS43060RTER
