TPS611 Datasheet – Phototransistor, LED – Toshiba ( PDF )

Part Number: TPS611

Function: Phototransistor

Package: Radial Type

Manufacturer: Toshiba

Image and Pinouts:

TPS611 datasheet



This is Silicon NPN Epitaxial Planar Phototransistor.


1. Photoelectric Counter
2. Various Kinds Of Readers
3. Position Detection


• φ5mm epoxy resin package(black)

• High sensitivity: IL = 120μA(typ.)

• Half value angle: θ1/2 = ±8°(typ.)

• Protected from external light by black mold packaging.

Official Site :


Other data sheets are available within the file: TPS611F
