XC6VLX130T Datasheet PDF – Field Programmable Gate Array

Part Number: XC6VLX130T

Function: FPGA – Field Programmable Gate Array

Package: FCBGA-1156 type

Manufacturer: Xilinx Inc


XC6VLX130T datasheet



The Virtex-6 family provides the newest, most advanced features in the FPGA market. Virtex-6 FPGAs are the programmable silicon foundation for Targeted Design Platforms that deliver integratedsoftware and hardware components to enable designers to focus on innovation as soon as their development cycle begins. Using the third-generation ASMBL (Advanced Silicon Modular lock) column based architecture, the Virtex-6 family contains multiple distinct sub-families.



1. Advanced, high-performance FPGA Logic

(1) Real 6-input look-up table (LUT) technology

(2) Dual LUT5 (5-input LUT) option

(3) LUT/dual flip-flop pair for applications requiring rich register mix

(4)  Improved routing efficiency

(5) 64-bit (or two 32-bit) distributed LUT RAM option per 6-input LUT

(6) SRL32/dual SRL16 with registered outputs option


Other data sheets are available within the file:


XC6VLX130T Datasheet PDF Download

XC6VLX130T pdf
