BTS7246 PDF – Smart High-Side Power Switch, BTS724G

A Smart High-Side Power Switch, often referred to simply as a “high-side switch” or “high-side power switch,” is an electronic component or module used in various applications to control the supply of electrical power to a load, device, or circuit. These switches are commonly used to manage the on/off state of loads in a smart or automated manner and often include additional features for protection, monitoring, and control.

Part Number: BTS7246

Corrector Part Number: BTS724G

Function: Smart High-Side Power Switch

Package: SO 20 Pin Type

Manufacturer: Infineon Technologies AG

Images:BTS7246 pdf pinout

Description

The BTS7246 is Smart High-Side Power Switch. ( Four Channels : 4 x 90mΩ )

1. N-channel vertical power MOSFET with charge pump, ground referenced CMOS compatible input and diagnostic feedback, monolithically integrated in Smart SIPMOS technology.

2. Providing embedded protective functions



Basic Functions :

1. Very low standby current

2. CMOS compatible input

3. Improved electromagnetic compatibility (EMC)

4. Fast demagnetization of inductive loads

5. Stable behaviour at undervoltage

6. Wide operating voltage range

7. Logic ground independent from load ground

Protection Functions  :

1. Short circuit protection

2. Overload protection

3. Current limitation

4. Thermal shutdown

5. Overvoltage protection (including load dump) with external resistor Reverse battery protection with external resistor

Block Diagram
BTS7246 datasheet

Applications:

1. µC compatible high-side power switch with diagnostic feedback for 12V and 24V grounded loads

2. All types of resistive, inductive and capacitve loads

3. Most suitable for loads with high inrush currents, so as lamps

4. Replaces electromechanical relays, fuses and discrete circuits

BTS7246 PDF Datasheet
