Part Number: EB13005
Function: 400V, NPN Transistor
Package: TO-220 Type
Manufacturer: SY ( Shenzhen SY Semiconductors )
Images:
1 page
2 page
Description
This is 400V, 5A, NPN Transistor.
Features：①HIGH VOLTAGE CAPABILITY ②HIGH SPEED SWITCHING
APPLICATION：
①FLUORESCENT LAMP
②ELECTRONIC BALLAST
●Absolute Maximum Ratings (Tc=25℃) TO-220 UNIT V V V A W ℃ ℃ 700 400 9 5.0 75 150 -65-150 NPN PARAMETER Collector– Base Voltage Collector– Emitter Voltage Emitter – Base Voltage Collector Current Total Power Dissipation Junction Temperature Storage Temperature SYMBOL VCBO VCEO VEBO IC PC Tj Tstg VALUE ● Electronic Characteristics (Tc=25℃) CHARACTERISTICS SYMBOL Collector– Base Cutoff Current Collector– Emitter Cutoff Current Collector– Emitter Voltage Emitter – Base Voltage Collector– Emitter Saturation Voltage Base– Emitter Saturation Voltage DC Current Gain Storage Time Falling Time ICBO ICEO VCEO VEBO Vcesat Vbesat HFE Ts Tf TEST CONDITION VCB=700v VCE=400v IC=10mA IB=0 IE=1mA IC=0 IC=1A IB=0.2A IC=4A IB=1A IC=1A IB=0.2A VCE=5v IC=10mA VCE=5v IC=1A VCE=5v IC=4A VCC=5V IC=0.5A MIN MAX 100 250 UNIT µ A µ A V V 400 9 0.5 1.5 1.5 7 10 5 2.0 4.0 1.0 40 V V V µ S µ S ●CLASSIFICATION OF HFE AND TS HFE TS 10-15 2.0-2.5 15-20 2.5-3.0 20-25 3.0-3.5 25-30 3.5-4.0 SY semiconductors 1/3 SY semiconductors Shenzhen SY Semiconductors Co.，LTD. EB SERIES TRANSISTORS EB13005 SY semiconductors 2/3 SY semiconductors Shenzhen SY Semiconductors Co.，LTD. EB SERIES TRANSISTORS SYMBOL A EB13005 SYMBOL L L1 D1 фb Q Q1 Z Min 3.5 1.25 0.75 0.6 0.35 14.0 9.0 Nom 4.5 1.35 0.85 0.43 15.5 10.0 2.54 Max 5.0 1.5 0.955 0.55 16.5 11.0 Min 12.5 2.5 5.9 1.5 2.0 3.0 Nom 13.5 3.37 6.5 2.5 2.6 3.8 Max 14.5 4.5 7.1 1.2 3.5 3.5 4.5 B B1 b c D E e SY semiconductors 3/3 […]
3 page
Absolute maximum ratings ( Ta=25°C )
1. Collector to Base Voltage: Vcbo = 700 V
2. Collector to Emitter Voltage: Vceo = 400 V
3. Emitter to Base Voltage: Vebo = 9 V
4. Collector Current: Ic = 5 A
5. Collector Dissipation : Pc = 75 W
6. Junction Temperature: Tj = 150°C
7. Storage Temperature: Tsg = -55 ~ +150°C
EB13005 Datasheet
