K3326 PDF Datasheet – 500V, 10A, N-Ch, MOSFET – NEC

This post explains for the K3326 mosfet.

The Part Number is 2SK3326.

The function of this semiconductor is 500V, 10A, MOSFET.

The package is TO-220 Type.

Manufacturer: NEC

Preview images :K3326 pdf pinout

Description

K3326 is N-Channel DMOS FET device that features a low gate charge and excellent switching characteristics, and designed for high voltage applications such as switching power supply, AC adapter.

An N-channel MOSFET (Metal Oxide Semiconductor Field Effect Transistor) is a type of field effect transistor (FET) that uses an N-type semiconductor material as the conducting channel to control the flow of current.

When a positive voltage is applied to the gate terminal, it attracts electrons to the channel, creating an inversion layer and allowing current to flow between the source and drain terminals.

N-channel MOSFETs are widely used in a variety of electronic applications due to their high input impedance, fast switching speeds, and low power consumption. They are commonly used as switches, amplifiers, and voltage regulators.

Features

• Low gate charge : QG = 22 nC TYP. (VDD = 400 V, VGS = 10 V, ID = 10 A)

• Gate voltage rating : ±30 V

• Low on-state resistance : RDS(on) = 0.85 Ω MAX. (VGS = 10 V, ID = 5.0 A)

• Avalanche capability ratings

• Isolated TO-220(MP-45F) package (Isolated TO-220)

K3326 datasheet mosfet

Absolute Maximum Ratings (Ta = 25°C)

1. Drain to source voltage: VDSS = 500 V

2. Gate to source voltage: VGSS = ± 30 V

3. Drain current: ID = 10 A

4. Total Power Dissipation: Pd = 2 W

Applications:

1. Switching: N-channel MOSFETs are used as electronic switches in many applications due to their ability to handle relatively high currents and voltages.

2. Amplification: MOSFETs can also be used for amplification purposes in certain configurations.

3. Voltage Regulation: They can be part of voltage regulation and control circuits.

K3326 PDF Datasheet
