B1326 Datasheet – PNP Transistor, (-)20V, (-)5A, Pinout

Posted on by pinout

Part Number: B1326

Function: (−20V, −5A) / PNP silicon transistor

Manufacturer: ROHM Semiconductor

Pinouts:

B1326 datasheet

Description

1) Low VCE(sat).  VCE(sat)= −0.35V (Typ.)  (IC/IB= −4A / −0.1A)

2) Excellent DC current gain characteristics.

3) Complements the 2SD2098 / 2SD2118 / 2SD2097.



components

Other data sheets are available within the file: 2SB1326

B1326 Datasheet PDF Download

B1326 pdf
