ECL86 PDF Datasheet – Triode Pentode ( Vacuum Tube )

Part Number: ECL86, PCL86

Function: Triode Pentode, Vacuum Tube

Package: Tube type

Manufacturer: RCA, Philips

Images:

ECL86 Datasheet Triode Pentode

Description

The ECL86 was one of the last triode plus output pentode valves designed and was released to the market in 1962. Uses were in domestic radio and audio equipment. Normally in single ended output stages for radio-grams and tape recorders. The design proved popular in low cost stereo systems. The ECL86 was preceded by the ECL82.

The triode section serves as a low-noise audio voltage amplifier or phase amplifier, providing sufficient gain to drive the power pentode stage. The pentode is optimized for single-ended Class A audio amplification and is capable of delivering several watts of output power with good linearity and low distortion when properly biased. Its separate cathode construction allows each section to be independently optimized, improving overall amplifier performance and offering greater design flexibility compared to earlier integrated valve designs.

Key Electrical Characteristics

  • Separate cathodes allow independent biasing of each section.
  • Triode section provides high voltage gain for audio preamplification.
  • Pentode section is optimized for low-frequency audio power amplification.
  • Suitable for single-ended Class A amplifier designs.
  • Capable of driving output transformers for loudspeaker applications.
  • Good linearity when operated within recommended plate voltage and current limits.
  • Heater designed for standard series heater supply operation.
  • Excellent compatibility with conventional analog audio circuits.
  • Well suited for low-to-medium power vacuum tube amplifier designs.

Pinout

ECL86 pinout

Design Considerations

  • Maintain proper heater voltage to ensure stable cathode emission and long tube life.
  • Select appropriate plate and screen voltages according to amplifier operating conditions.
  • Use separate cathode bias components for the triode and pentode sections when required.
  • Choose an output transformer with the correct primary impedance for maximum performance.
  • Provide adequate chassis ventilation since the valve dissipates significant heat.
  • Keep high-impedance grid wiring short to minimize hum and unwanted oscillation.
  • Use proper grounding techniques to reduce noise in sensitive audio circuits.
  • Install quality filter capacitors in the high-voltage power supply to suppress ripple.
  • Avoid exceeding maximum plate dissipation to improve reliability and tube longevity.
  • Allow sufficient spacing between valves to reduce thermal interaction in multi-tube amplifiers.

Typical Circuit Configurations

  • Single-ended Class A integrated audio amplifier.
  • Compact stereo amplifier using one ECL86 per channel.
  • Radio receiver audio output stage.
  • Tape recorder playback amplifier.
  • Phonograph amplifier with integrated voltage and power stages.
  • Educational vacuum tube amplifier demonstration circuits.
  • Vintage public-address amplifier systems.
  • Retro guitar practice amplifiers with low output power.

Performance Advantages

  • Reduces component count by integrating two active devices in one envelope.
  • Simplifies amplifier layout and wiring.
  • Produces the characteristic warm sound associated with vacuum tube amplifiers.
  • Excellent linear performance for low-power audio reproduction.
  • Separate cathodes provide flexible biasing options.
  • Well proven through decades of audio equipment applications.
  • Suitable for restoration of classic European audio equipment.
  • Requires relatively simple supporting circuitry.

Typical Applications

  • Vintage hi-fi integrated amplifiers.
  • Domestic tabletop radio receivers.
  • Reel-to-reel tape recorders.
  • Portable record players and phonographs.
  • Compact stereo audio systems.
  • Educational electronics laboratories.
  • Vacuum tube restoration projects.
  • Custom boutique audio amplifiers.
  • Low-power musical instrument amplifiers.
  • Collector-grade reproduction audio equipment.

Comparison with Similar Components

Device Main Difference Typical Use
ECL82 Earlier generation with lower output capability. Compact radio and audio amplifiers.
PCL86 Electrically similar but designed for a different heater voltage. Television and audio equipment with series heater strings.
ECL805 Primarily intended for television vertical deflection applications. TV circuits and specialized amplifier designs.
EL84 + ECC83 Uses separate power and preamplifier tubes for higher flexibility. Higher-performance hi-fi and guitar amplifiers.

Frequently Asked Questions

Q1. Can the ECL86 replace an ECL82 directly?

Not always. Although both are triode-pentode valves, their electrical characteristics, operating conditions, and circuit requirements differ, so direct substitution is generally not recommended without circuit modifications.

Q2. What factors most affect the reliability of an ECL86 amplifier?

Proper heater voltage, controlled plate dissipation, adequate cooling, quality power supply filtering, and correct bias adjustment are the primary factors influencing long-term reliability.

Q3. What should be considered when laying out an amplifier using the ECL86?

Keep signal paths short, separate high-voltage wiring from low-level audio signals, use effective grounding techniques, and position the output transformer to minimize magnetic hum coupling.

ECL86 PDF Datasheet

 pdf

ECL86 Datasheet

AMS1117 Datasheet PDF – 800mA, Voltage Regulator – AMS

Part Number: AMS1117

Function: 800mA, LOW DROPOUT VOLTAGE REGULATOR

Package: SOT-223, TO-252 (DPAK) Type

Manufacturer: Advanced Monolithic Systems

Image:AMS1117

Description

The AMS1117 series of adjustable and fixed voltage regulators are designed to provide 800mA output current and to operate down to 1V input-to-output differential. The dropout voltage of the device is guaranteed maximum 1.3V at maximum output current, decreasing at lower load currents.

Its simple three-terminal design and minimal external component requirements make it a popular choice for power regulation in embedded systems, microcontrollers, communication modules, consumer electronics, and industrial equipment.

On-chip trimming adjusts the reference voltage to 1%. Current limit is also trimmed, minimizing the stress under overload conditions on both the regulator and power source circuitry. The AMS1117 devices are pin compatible with other three-terminal SCSI regulators and are offered in the low profile surface mount SOT-223 package and in the TO-252 (DPAK) plastic package.

Key Features

  • Low Dropout (LDO) linear voltage regulator
  • Output current up to 800mA
  • Dropout voltage of 1.3V maximum at full load
  • Output voltage accuracy: ±1%
  • Available in adjustable and fixed output versions
  • Fixed output options: 1.2V, 1.5V, 1.8V, 2.5V, 2.85V, 3.3V, and 5V
  • Excellent load regulation
  • Typical load regulation: 0.2%
  • Optimized for low-voltage applications
  • Internal current limiting
  • Thermal overload protection
  • Three-terminal regulator architecture
  • Compatible with standard SOT-223 and TO-252 (DPAK) packages

AMS1117 Pinout

AMS1117 Datasheet

Protection Features

  • Internal current limiting
  • Thermal shutdown protection
  • Safe operating area protection
  • Precision trimmed reference voltage
  • Short-circuit protection through current limiting

Design Notes

  • The input voltage must exceed the desired output voltage by at least the dropout voltage. For example, an AMS1117-3.3 typically requires about 4.6V or higher input to maintain proper regulation at full load.
  • Input and output bypass capacitors should be placed close to the regulator pins to improve stability and transient response.
  • Power dissipation is calculated as (VIN − VOUT) × IOUT. Adequate PCB copper area or a heatsink may be necessary for high current or large input-to-output voltage differences.
  • The adjustable version requires two external resistors to set the output voltage according to the internal reference voltage.
  • Although rated for 800mA, the maximum usable output current depends on thermal conditions and PCB layout.
  • The regulator is intended for linear regulation and is not suitable where high conversion efficiency is required; in such cases, a switching regulator is preferred.

Applications

  • Consumer electronics
  • IoT devices
  • Networking equipment
  • Portable instruments
  • LCD display modules
  • Development boards (Arduino, STM32, ESP32, Raspberry Pi accessories)
  • Medical instrumentation
  • Automotive electronics (within operating voltage limits)

Alternative / Equivalent Products

  • LM1117 Series
  • LD1117 Series
  • NCP1117 Series
  • AZ1117 Series
  • AP1117 Series
  • TLV1117 Series
  • MIC39100 (higher current LDO alternative)
  • MCP1825 (low-dropout alternative)

AMS1117 Datasheet
