UPC1298V PDF – Audio Power Amplifier ( Datasheet )

Posted on by pinout

Part Number: UPC1298V

Function: 50 to 80 W power amplifier driver

Package: 14 Pin type

Manufacturer: NEC ( Renesas Technology )

Image:

UPC1298V datasheet

Description

UPC1298V is a monolithic power amplifier driver IC from NEC (Renesas), designed for 50W to 80W class HiFi audio amplifier applications in a 14-pin package. It integrates a differential input stage, predriver, driver circuitry, and overcurrent protection to simplify high-power audio amplifier design. This device offers low distortion performance with wide frequency and power bandwidth, making it suitable for high-fidelity audio systems.

Features

  • Integrated power amplifier driver for 50W to 80W output stages
  • Low distortion characteristics for high-quality audio reproduction
  • Wide frequency bandwidth of approximately 900kHz (-3dB)
  • Wide power bandwidth of approximately 90kHz
  • Built-in input differential amplifier
  • Integrated predriver and driver stages
  • Overcurrent protection circuit included
  • 14-pin package for compact amplifier designs

Block Diagram and Pinouts

UPC1298V pinouts

Design Notes

  • Proper heat sinking is required for the external output stage transistors in high-power designs
  • Use symmetric PCB layout to minimize distortion and maintain signal integrity
  • Power supply decoupling is critical to avoid oscillation at high frequencies
  • Ensure correct biasing of the output stage to reduce crossover distortion
  • Overcurrent protection should be validated with real load conditions

How to Choose This Part

  • Select for medium-to-high power audio amplifier designs (50W to 80W range)
  • Suitable for applications requiring low distortion and wide bandwidth
  • Ideal when integrating driver and protection circuits in a single IC
  • Consider for designs using discrete output transistors

Applications

  • Home audio HiFi systems
  • Audio amplifiers and receivers
  • Professional sound equipment
  • Multimedia speaker systems

Alternative / Equivalent Products

  • UPC1297V
  • TA7317P
  • LM4702
  • STK amplifier modules (integrated alternatives)

UPC1298V Datasheet PDF Download


UPC1298V pdf

Other data sheets are available within the file: UPC1298, μPC1298V

FN-M16P Datasheet PDF – MP3 Audio Voice Module SD

Posted on by pinout

Part Number: FN-M16P

Function: MP3 audio module, voice module SD

Package: Module type

Manufacturer: Flyron Technology

Image :
WTV020M01-Pinout

Description

FN-M16P module is a serial MP3 module that is with a perfect integrated MP3 and WMV decoder chip. It provides micro SD card driver, and supports FAT16 and FAT32 file systems. It is able to play back specified sound files and realize other functions through simple serial commands. In the mean time, this module supports AD key control mode that facilitates users to develop their jobs in some simple applications. Without the cumbersome underlying operating, easy to use, stable and reliable are the most important features of this module.

Features

1. Supports MP3 and WAV decoding.

2. Supports FAT16 and FAT32 file system.

3. 24-bit DAC output and supports dynamic range 90dB and SNR 85dB.

4. Supports AD key control mode and UART RS232 serial control mode.

5. Supports maximum 32GB micro SD card and 32GB USB flash drive.

6. Audiofiles are sorted by folders; supports up to 99 folders, and each folder can be assigned to 255 sound files.

7. Supports inter-cut advertisements.

8. Supports playback of specifying folders.

9. Support random playback.

10. Built-in 3W amplifier that can direct drive a 3W/8Ohm speaker.

11. 30 levels adjustable volume, and 6 levels adjustable EQ.

Pinout

FN-M16P Pinout

Design Notes

  • UART interface allows straightforward integration with microcontrollers (e.g., MCU, Arduino)
  • AD key mode enables standalone operation using resistor ladder inputs
  • Ensure proper power supply decoupling to avoid audio noise
  • Speaker outputs can directly drive small speakers (typically 8Ω)
  • File naming and folder structure on microSD must follow module requirements
  • Use FAT16/FAT32 formatted microSD cards for compatibility

How to Choose This Part

  • Select for simple audio playback without complex DSP requirements
  • Ideal for low-cost designs requiring serial control
  • Ensure compatibility with system voltage and UART logic levels
  • Evaluate need for onboard amplification vs external audio stages
  • Consider storage capacity requirements of microSD card

Applications

  • MP3 players and voice modules
  • Smart home voice alerts
  • Industrial warning systems
  • Educational and DIY electronics projects
  • Portable audio devices

Alternative / Equivalent Products

  • DFPlayer Mini (YX5200-based MP3 module)
  • WT2003S audio playback module
  • JQ6500 voice module
  • VS1053 MP3 decoder module
  • ISD1820 voice recording/playback module (for recording applications)

FN-M16P Datasheet PDF Download

FN-M16P pdf



Reference Informations

WTV020M01 Datasheet

WTV020M01 pdf
WTV020M01

WTV020M01 Features

1. The product supports plug-maximum the 1G capacity of the SD card

2. Supports playback of 4Bit ADPCM format files

3. Automatically recognize the voice files

4. Loadable 6KHz to 32KHz, 36KHz sampling rate AD4 audio

5. Loadable 6KHz ~ 16KHz sampling rate WAV audio

6. 16bitDAC and PWM audio output

7. Can store up to 512 voice

8. WTV020-SD-20S, WTV020-SD-16P two module types

9. Support micro-processor and key control

10. Voice playback can call any paragraph

11. Power-down save operation data capabilities

12. Loaded voice without software assistance to the SD card can be placed directly on the voice

13. Support file combination play, including mute combination

14. Operating voltage: DC 2.5 ~ 3.6V

15. Quiescent Current: 16uA (SD card is not inserted)
