This is PWM Controller.
Part Number: LM5033
Function: 100V, Push-Pull Voltage Mode PWM Controller
Package: VSSOP, WSON, LLP-10 (4 x 4 mm) type
Manufacturer: Texas Instruments
Pinouts:
Description
The LM5033 High Voltage PWM controller contains all the features needed to implement Push-Pull, Half-Bridge, and Full-Bridge topologies. Applications include closed loop voltage mode converters with a highly regulated output voltage, or an open loop “DC transformer” such as an Intermediate Bus Converter (IBC) with an efficiency >95%. Two alternating gate driver outputs with a specified deadtime are provided.
The LM5033 includes a start-up regulator that operates over a wide input range of 15V to 100V. Additional features include: precision voltage reference output, current limit detection, remote shutdown, softstart, sync capability and thermal shutdown. This high speed IC has total propagation delays less than 100 ns and a 1MHz capable oscillator.
Features
• Internal High Voltage (100V) Start-Up Regulator
• Single Resistor Oscillator Setting
• Synchronizable
• Precision Reference Output
• Adjustable Soft-Start
• Over-Current Protection
• Direct Optocoupler Interface
• 1.5A Peak Gate Drivers
• Thermal Shutdown
Applications:
1. Intermediate DC-DC Bus Converter
2. Telecommunication Power Converters
3. Industrial Power Converters
Other data sheets are available within the file: LM5033MM, LM5033MM/NOPB, LM5033MMX/NOPB, LM5033SD
LM5033 Datasheet PDF Download
