This post describes for the HDMI Receiver. HDMI 1.3 refers to a version of the High-Definition Multimedia Interface (HDMI) specification. HDMI is a digital interface used for transmitting high-definition audio and video signals between devices such as TVs, monitors, and audio/video receivers.
The Part Number is SIL9135.
The function of this semiconductor is HDMI V1.3 Receiver.
The Package is TQFP 144 Pin type.
The manufacturer of this part is Silicon Image.
See the preview image and the PDF file for more information.
1 page
Description
The SiI9135 is a second generation HDMI v1.3 Receiver. It is software compatible with the SiI9133, but adds audio support for DTS-HD and Dolby TrueHD. Digital televisions that can display 10/12-bit color depth can now provide the highest quality protected digital audio/video over a single cable. The SiI9135 can receive deep color video up to 12-bit, 1080p@60Hz. Backward compatibility with DVI 1.0 allows HDMI systems to connect to existing DVI 1.0 hosts, such as HD set-top boxes and PCs. The specialized audio and video processing contained in the receiver can add HDMI capability to earliergeneration consumer electronics. Efficient color space conversion receives RGB video data and outputs either standard-definition or high-definition YCbCr formats.
[…]
2 page
Features:
1. Dual-Input HDMI 1.3, HDCP 1.1, and DVI 1.0 compliant Receiver
2. Integrated TMDS core running at 25 – 225 MHz
3. Integrated HDCP decryption engine for receiving
4. Flexible power management
An HDMI 1.3 receiver is a device that can receive HDMI signals and decode them for output to a TV or other display device. It is typically used in audio/video receivers or home theater systems to connect various HDMI sources, such as Blu-ray players, gaming consoles, or set-top boxes, to a compatible display.
SIL9135 PDF Datasheet
