TDA4568 Datasheet PDF – Signal Delay, Philips

Part Number: TDA4568

Function: Luminance signal delay circuit

Package: DIP 18 Pin Type

Manufacturer: Philips Electronics ( https://www.nxp.com/ )

Image:

TDA4568 datasheet



Description

The TDA4568 is an integrated circuit that provides the luminance signal delay in colour television receivers.

Block diagram :

TDA4568 block diagram

Features

1. A luminance signal path (Y) which substitutes the conventional Y-delay coil with an integrated Y-delay line

2. Switchable delay time from 550 ns to 820 ns in steps of 90 ns and additional fine adjustment of 37 ns

3. Two Y output signals; one of 180 ns less delay



TDA4568 Datasheet PDF Download


TDA4568 pdf

Other data sheets are available within the file: TDA-4568
