PEMB11 Datasheet – PNP/PNP Resistor-Equipped Transistor

Part Number: PEMB11

Marking Code : B1

Function: PNP/PNP resistor-equipped transistors; R1 = 10 k Ohm, R2 = 10 k Ohm

Package: SMD SOT-666 Type

Manufacturer: NXP Semiconductors.

Pinouts:

PEMB11 datasheet



Description

PNP/PNP Resistor-Equipped Transistors (RET) in Surface-Mounted Device (SMD) plastic packages.

Features

1. 100 mA output current capability

2. Reduces component count

3. Built-in bias resistors

4. Reduces pick and place costs

5. Simplifies circuit design

6. AEC-Q101 qualified

Applications:

1. Low current peripheral driver

2. Control of IC inputs

3. Replaces general-purpose transistors in digital applications

PEMB11 Datasheet PDF Download


PEMB11 pdf

Other data sheets are available within the file: PEMH11, PUMB-11, PUMH11
