Part Number: PPN13LB10C
Function: Minebea Motor, DC Brush Motor
Manufacturer: NMB-MAT
Images:
Description
PPN13LB10C is 10V Mini DC Brush Motor ( Mirco Spindle Brush DC Motor ). A DC brush motor, also known as a brushed DC motor or simply a brushed motor, is a type of electric motor that relies on brushes and a commutator to transfer electrical power to the rotating armature (rotor). It is one of the oldest and most straightforward types of electric motors, commonly used in various applications due to its simplicity and cost-effectiveness.
DC brush motors have several advantages, such as simplicity, low cost, and ease of control using variable voltage (speed control) or pulse-width modulation (PWM). However, they also have some drawbacks, including wear and maintenance due to the mechanical brushes and commutator, as well as limited lifespan compared to brushless motors.
DC UNIT: mm Specifications Model Operating Voltage (V) Rated Voltage (V) 2 5 5 5 7.4 9.6 7.4 2.0 8.0 4.0 No Load Speed (r/min) 3830 4610 8700 6160 10300 11350 9100 3150 7600 5600 No Load Current (mA) 35 17 35 20 40 25 34 34 25 33 Rated Load (gf·cm) 2.0 3.0 15.0 4.0 7.5 5.0 7.5 2.0 12.0 5.0 (mN·m) 0.196 0.294 1.471 0.392 0.735 0.490 0.735 0.196 1.176 0.490 Rated Load Speed (r/min) 3315 3660 3900 5230 8150 9700 7450 2700 5100 4650 Rated Current (mA) 80 51 320 75 175 100 142 70 145 110 Starting Torque (gf·cm) 14.0 14.5 28.5 26.4 36.0 37.0 41.6 15.1 36.7 29.1 (mN·m) 1.373 1.422 2.795 2.587 3.530 3.628 4.080 1.480 3.600 2.850 Shaft Length (mm) a=11 a=11 a=11 a=11 a=11 a=6 a=11 a=11 a=11 a=11 PPN13KA12C 1.5 to 2.5 PPN13KB08C 2.7 to 7.5 PPN13KA11C 1.6 to 6.0 PPN13LB10C 3.5 to 10.0 PPN13KB10C 3.5 to 7.5 PPN13KB09A 5.0 to 11.0 PPN13PB11C 0.5 to 10.0 PPN13PB125C 1.0 to 7.4 PPN13PB10C 1.0 to 10.0 PPN13PB12C 1.0 to 7.0 Characteristics Current (mA) Speed (r/min) Current (mA) 1000 10000 at 5V Speed (r/min) PPN13KA11C 1000 8000 PPN13LB10C at 5V 500 5000 500 4000 0 20 2.0 40 Torque(gf·cm) Torque(mN·m) Current (mA) at 7.4V Speed (r/min) 0 20 2.0 40 Torque(gf·cm) Torque(mN·m) at 9.6V Current (mA) 1200 Speed (r/min) 12000 PPN13KB10C 1200 12000 PPN13KB09A 600 6000 600 6000 Current (mA) Speed (r/min) 1000 10000 0 20 2.0 40 Torque(gf·cm) Torque(mN·m) Current (mA) Speed (r/min) 0 20 2.0 40 Torque(gf·cm) Torque(mN·m) at 5V PPN13PB11C at 5V 500 5000 PPN13PB125C 500 5000 250 2500 0 20 2.0 40 Torque(gf·cm) Torque(mN·m) 0 10 1.0 20 Torque(gf·cm) Torque(mN·m) Copyright Minebea Co., Ltd. […]
