103H7123-5040 PDF Datasheet – 2-phase Stepping Motor

This post explains for the Stepping Motor.

The Part Number is 103H7123-5040.

The function of this semiconductor is 56mm, 2-phase Stepping Motor.

Manufacturer: Sanyo Denki

Preview images :

1 page
103H7123-5040 pdf motor

Description

103H7123-5040 is Bipolar winding, 56mm, 2-phase Stepping Motor.

A 2-phase stepping motor, also known as a bipolar stepper motor, is a type of electric motor commonly used in various applications where precise control of rotational motion is required. It is called “2-phase” because it has two sets of windings, or phases, in its stator. These motors are known for their ability to move in discrete steps or increments, making them valuable in applications such as robotics, 3D printers, CNC machines, and more.

Specifications:

1. Motor Type : Hybrid Motor

2. Step Angle : 1.8 °

3. Rated Current : 2 A

4. Phase Current : 2 A

5. Number of Wires : 4

6. Number of Phases : 2

7. Inductance : 3.8 mH

8. Resistance Per Phase : 800 mOhm

9. Rotor Inertia : 210 gcm²

10. Operating Mode : Bipolar

11. Holding Torque : 830 Nmm

12. Shaft Length : 21 mm

13. Shaft Diameter : 6.4 mm

14. NEMA Size : NEMA 23

15. Series : SanMotion

16. Length : 54 mm

17. Width : 56 mm

18. Height : 56 mm

103H7123-5040 datasheet

Ordering Informations :

103H7121-0140
103H7121-0440
103H7121-0740
103H7123-0140
103H7123-0440
103H7123-0740
103H7124-0140
103H7124-0440
103H7124-0740
103H7126-0140
103H7126-0440
103H7126-0740



103H7123-5040 PDF Datasheet

Posts related to ‘ Stepping Motor

Part number Description
103H7126 2-phase Stepping Motor ( PDF )
PH266-01 6V, Stepping Motor
103H7124 2-phase Stepping Motor
TB6600 Stepping Motor Driver ( PDF )
35S1N15D7YA Stepping Motor – Mitsumi
M42SP-6 42mm, Stepping Motor – Mitsumi
SI-7510 5-Phase stepping Motor Driver – Sanken
GSP-24RW-02 DC 12V, Stepping Motor
M42SP-5 Stepping Motor
103H7126 103H7126 PDF – 2-Phase Stepping Motor – Sanyo



23HS8430 PDF – 76mm, 2 Phase Hybrid Stepper Motor

Part Number: 23HS8430

Function: 76mm, 2 Phase Hybrid Stepper Motor

Package: Module type

Manufacturer: MotionKing

1 page

23HS8430 Stepper Motor

Description

23HS8430 is 2 Phase Hybrid Stepper Motor 23HS series-Size 57mm(1.8 degree).

A 2-phase hybrid stepper motor is a type of stepper motor that operates with two phases. It is a popular choice for precision positioning applications due to its ability to provide precise angular displacement and control. The term “hybrid” refers to the combination of aspects from both permanent magnet (PM) and variable reluctance (VR) stepper motor designs.

Features:

1. Two Phases: The motor has two sets of windings, often referred to as phase A and phase B. Each phase has its own coil windings and associated driver circuitry.

2. Stator and Rotor: The motor consists of a stator, which contains the coils or windings, and a rotor, which has teeth or poles. The rotor typically has a permanent magnet structure or a combination of permanent magnets and soft iron teeth.

3. Precise Control: The motor’s step angle, or the angular displacement per electrical input, is typically small, such as 1.8 degrees per step or even smaller, allowing for precise control and positioning.

4. Bi-polar Configuration: A 2-phase hybrid stepper motor is typically configured in a bipolar configuration, meaning that each phase has two terminals that require a bipolar stepper motor driver to control the motor’s operation.

Specifications:

1. Step Accuracy : ±5%

2. Resistance Accuracy : ±10%

3. Inductance Accuracy : ±20%

4. Temperature Rise : 80°C MAX.

5. Ambient Temperature Range : -20°C~ +50°C

6. Storage Temperature Range : -30°C~ +60°C

7. Insulation Resistance : 100M Ω MIN. 500V DC

8. Dielectric Strength : 500V AC 1min

9. Radial Play : 0.02mm MAX. (450g Load)

10. End Play : 0.08mm MAX. (450g Load)

11. Max. Radial force : 75N

12. Max. Axial force : 15N



MotionKing (China) Motor Industry Co., Ltd. HB Stepper Motor Catalog Wiring Diagram: UNI-POLAR(6 LEADS) BI-POLAR(4LEADS) Electrical Specifications: Series Model Step Angle (deg) Motor Length (mm) Rated Phase Phase Holding Detent Rotor Current Resistance Inductance Torque Torque Inertia (A) (ohm) (mH) (N.cm Min) (N.cm Max) (g.cm²) Lead Motor Wire Weight (No.) (g) 23HS0601 1.8 41 1.0 5.2 5.5 23HS0405 1.8 41 0.62 12 24 23HS0408 1.8 41 2.0 1.2 2.5 23HS4412 1.8 45 0.62 12 26 23HS4425 1.8 45 2.5 1.0 2.2 23HS5406 1.8 51 0.62 13 28 23HS5425 1.8 51 2.5 1.2 3.2 23HS5602 1.8 51 0.8 6.8 9.2 23HS6602 1.8 56 1.5 3.2 5.5 23HS6403 1.8 56 2.5 1.3 3.6 23HS6430 1.8 56 3.0 0.8 2.4 23HS6404 1.8 56 4.2 0.4 1.2 23HS7401 1.8 64 1.0 7.5 20 23HS7425 1.8 64 2.5 1.5 4.5 23HS7430 1.8 64 3.0 0.8 2.3 23HS7404 1.8 64 4.2 0.55 1.2 23HS8603 1.8 76 1.5 4.5 10 23HS8425 1.8 76 2.5 1.8 6.5 23HS8430 1.8 76 3.0 1.0 3.5 23HS8404 1.8 76 4.2 0.6 1.8 23HS1430 1.8 100 3.0 1.4 5.5 23HS1410 1.8 100 4.2 0.8 3.0 23HS2430 1.8 112 3.0 1.6 6.8 23HS2410 1.8 112 4.2 0.9 3.8 *Note: We can manufacture products according to customer’s requirements. 40 55 55 80 80 90 90 63 90 110 110 110 150 150 150 150 140 180 180 180 250 250 280 280 2.5 150 6 470 2.5 150 4 470 2.5 150 4 470 2.8 190 4 520 2.8 190 4 520 2.8 190 4 520 2.8 190 4 520 3.0 230 6 590 3.5 280 6 590 3.5 280 4 680 3.5 280 4 680 3.5 280 4 680 5.0 380 4 850 5.0 380 4 850 5.0 380 4 850 5.0 380 4 850 6.0 440 6 1050 6.0 440 4 1050 6.0 440 4 1050 6.0 440 4 1050 10 680 4 1250 10 680 4 1250 12 800 4 1400 12 800 4 1400 12 www.MotionKing.com MK1106, Rev.04 MotionKing (China) Motor Industry Co., Ltd. Dimensions: unit=mm HB Stepper Motor Catalog Motor Length: Model 23HS0XXX 23HS4XXX 23HS5XXX 23HS6XXX 23HS7XXX 23HS8XXX 23HS1XXX 23HS2XXX Length 41 mm 45 mm 51 mm 56 mm 64 mm 76 mm 100 mm 112 mm 13 www.MotionKing.com MK1106, Rev.04 […]

23HS8430 pdf





23HS8430 PDF Datasheet
