FTP11N08N PDF Datasheet – 75V, 100A, N-Ch, MOSFET

This post explains for the MOSFET.

The Part Number is FTP11N08N.

The function of this semiconductor is 75V, 100A, N-Channel MOSFET.

The package is TO-220 Type

Manufacturer: IPS

Preview images :

FTP11N08N pdf datasheet

Description

FTP11N08N is 75V, 100A, N-Channel MOSFET.

An N-channel MOSFET (Metal Oxide Semiconductor Field Effect Transistor) is a type of field effect transistor (FET) that uses an N-type semiconductor material as the conducting channel to control the flow of current.

When a positive voltage is applied to the gate terminal, it attracts electrons to the channel, creating an inversion layer and allowing current to flow between the source and drain terminals.

N-channel MOSFETs are widely used in a variety of electronic applications due to their high input impedance, fast switching speeds, and low power consumption. They are commonly used as switches, amplifiers, and voltage regulators.

Features

• RoHS Compliant

• Low ON Resistance

• Low Gate Charge

• Peak Current vs Pulse Width Curve

• Inductive Switching Curves



FTP11N08N pinout mosfet

Applications:

• Automotive

• DC Motor Control

• Class D Amplifier

FTP11N08N PDF Datasheet
