The BAW56 is a dual common cathode switching diode in a small SOT-23 surface-mount package.
Part Number: BAW56
Marking : JD
Function: 70V, 250mA, Small Signal Switching Diode, Dual
Manufacturer: Vishay Semiconductors
Image and Pinouts:
What is BAW56?
The BAW56 is a dual common cathode switching diode that is commonly used in a variety of applications. It features two diodes connected in a common cathode configuration, allowing it to be used for switching, blocking, and clamping circuits.
It has two diodes connected in a common cathode configuration, making it useful in various applications like switching, blocking, and clamping circuits.
This is Small Signal Switching Diode.
Features
• Silicon epitaxial planar diode
• Fast switching dual diode with common anode
• AEC-Q101 qualified
• Base P/N-E3 – RoHS-compliant, commercial grade
• Base P/N-HE3 – RoHS-compliant, AEC-Q101 qualified
Advantages and disadvantages of using
Advantages:
1. High switching speed makes it useful in high-frequency applications
2. Low capacitance and leakage current make it suitable for low-power applications
3. Small surface-mount package saves space and enables automated assembly
4. Dual diode configuration saves board space and simplifies circuit design
Disadvantages:
1. Maximum forward current of 250 mA limits its use in high-power applications
2. Maximum reverse voltage of 70 V may not be sufficient for certain applications
3. Low capacitance may limit its use in applications that require higher capacitance values
Mechanical Data:
1. Case : SOT-23 Type
2. Weight : approx. 8.8mg
Applications:
1. Switching circuits
2. Blocking circuits
3. Clamping circuits
4. High-frequency applications
5. Low-power applications
6. Signal processing circuits
