Part Number: SVF7N65FQ
Function: 7A, 650V, MOSFET (Transistor)
Package: TO-220, TO-263 Type
Manufacturer: Silan Microelectronics
Images:
Description
The SVF7N65FQ is an N-channel enhancement mode power MOS field effect transistor which is produced using Silan proprietary F-CellTM structure VDMOS technology. The improved process and cell structure have been especially tailored to minimize on-state resistance, provide superior switching performance, and withstand high energy pulse in the avalanche and commutation mode. These devices are widely used in AC-DC power suppliers, DC-DC converters and H-bridge PWM motor drivers.
Pinouts:
Features:
1. 7A, 650V, RDS(on)(typ.)=1.1Ω@VGS=10V
2. Low gate charge
3. Low Crss
4. Fast switching
5. Improved dv/dt capability
Ordering Informations:
Applications:
Other data sheets are available within the file: SVF7N65CFQ, SVF7N65CS, SVF7N65CF, SVF7N65C
SVF7N65FQ PDF Datasheet
